Specifications

Tuning range: FM, MW

Power output: 120 watts per channel into 8Ω (stereo)

Frequency response: 10Hz to 50kHz

Total harmonic distortion: 0.1%

Damping factor: 25

Input sensitivity: 6.5mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)

Signal to noise ratio: 75dB (MM), 90dB (line)

Output: 150mV (line), 30mV (DIN), 1V (Pre out)

Semiconductors: 4 x FET, 5 x IC, 79 x transistors, 49 x diodes

Dimensions: 526.6 x 173 x 453.5mm

Weight: 23.4kg

Year: 1976
