Type
Belt drive

Motor
24 Pole Synchronous
Acetal Spindle Thrust Bearing

Motor Mount
Axially De-coupled

Pulley
Super Precision Aluminium Alloy

Drive Belt
Bespoke Silicone Rubber

Platter DG-1
         Precision Machined Aluminium Alloy
PETG Bonded Record Interface Mat
 Underside Bonded Resonance Control Disc and Bonded Protective Cork/Neoprene/Nitrile Disc

Bearing Spindle DG-1
Non Magnetic Stainless Steel
Super Precision Machined and Polished

Roundness / Concentricity
< 5 Microns

Bearing Housing
Brass
Super Precision Machined
Bore Tolerance < 5 Microns
Super Precision Tungsten Carbide Ball

Plinth Structure
3 Layer Cast Acrylic
Middle Clear Plinth, Internally Illuminated

Isolation System
6 Point, Bespoke Silicone Rubber

Support Structure
Black Coated Zintec Steel Chassis
Three Adjustable Feet with Resistive Felt

Motor Drive
Advanced Microprocessor Controlled
Fully Programmable with Motor Noise Reduction
Bridged Balanced Motor Output Amplifiers

Speeds
33.3 and 45 rpm (+/- 0.2%)
Electronically Selectable

Dust Cover
Bespoke Formed Tinted Polycarbonate

Dimensions (W x D x H)
469 x 384 x 130mm (including dust cover)

Power Supply
Wall Adaptor Type
UK, US, EU and AUS Exchangeable Plugs
100 – 240 Vac with 1.5m Cord

Finishes
Black and white gloss

Weights
8kg - Net
