echnical Specifications

Output power:  200W + 200W in 8 ohms, 350W + 350W in 4 ohms
Inputs:  CD (RCA), Aux (RCA) and balanced (XLR)
Home Theatre input:  Fixed to level 85 (RCA)
Outputs:  2 pcs Pre Out (RCA), 1 pcs Recording output (RCA)
Speaker outputs:  Two pairs of heavy duty gold plated terminals
Input impedance:  Balanced 50kohm, unbalanced 11kohm
Frequency response:  Less than +/- 0.2 dB deviation 20Hz-20kHz
Phase Response:  Less than 2 degrees deviation 20Hz- 20kHz
Signal to noise ratio:  More than 100dB
Crosstalk:  Less than -100dB
Distortion:  Less than 0.006 % at 100W i 8 ohm
Intermodulation:  Less than 0.01 % (19kHz + 20kHz)
Damping factor:  More than 1000
Power Supply:  1000VA dual mono, 90 000uF capacitors
Output stage:  20 pcs 15A 150W high speed bipolar transistors
Power consumption:  60W in standby switched on
Dimensions: 120 x 430 x 380mm

Weight 25kg
Category HiFi Components
Sub Category Amplifiers
